Partner P738 - IDENTIFICATION (WHAT IS WHAT?); IDENTIFICATION OF SYMBOLS

2
IDENTIFICATION (WHAT IS WHAT?)
Chain
Adjustment Tool
(Bar Tool)
Bar Oil Fill Cap
Chain
Front Hand Guard
Starter Rope
ON/STOP
Switch
Muffler
Choke/
Fast Idle
Lever
Fuel Mix Fill Cap
Starter Housing
Idle Speed Screw
Bumper
spike
Primer Bulb
Front Handle
Guide Bar
Bar Nuts
Cylinder Cover
Throttle
Lockout
Rear
Handle
Throttle
Trigger
Chain
Brake
Chain
Direction
of Travel
Adjusting Screw
Chain
Catcher
Clutch Cover
IDENTIFICATION OF SYMBOLS
WARNING! This chain
saw can be dangerous! Care-
less orimproper use cancause
serious or even fatal injury.
Read and understand the
instruction manual before
using the chain saw.
Always use two
hands when
operating the
chain saw.
WARNING! Contacting the guide bar tip with any object
should be avoided; tip contact may cause the guide bar to
movesuddenlyupwardandbackward,whichmay causese-
rious injury.
Always wear appropriateear
protection, eye protection
and head protection.
Sound power level
Sound pressure level
at 7,5 meters
