The connection with an external thermostat is a clean
contact.
External thermostat installation
The operation of the stove can be adjusted by any external room
thermostat with external clean contact, connected to the electronic
board (see wiring diagram). The thermostat is connected by
connecting the 2 wires to the terminal board marked in the figure.
The contact to be used is of the NO type (Normally open), if there
is no clean contact, place a relay between the thermostat and the
terminal board of the machine.
The connection of unsuitable thermostats could damage the
electronic board in an irreparable way.
This operation must be carried out by specialized personnel.
To activate the thermostat, press the power button for a few
seconds: after the start phase, if the thermostat is off, the words
"wait coiling" will come out, indicating the standby status of the
appliance itself.
