(figura 18 )
(figura 19 )
(figura 20)
(figura 21)
(figura 22)
(figura 24)
(figura 23)
Remove the deflector from the stove, remove the top cover (figure 18) unscrew
the cap below it fixed with bolts (figure 19). In the CP models, the cap is always
accessible by lifting the top cover (figure 19)
Disassembling, therefore, these caps, it will be possible to access the tube bundle
you will have to use a brush or tube long enough to reach the entire length of the
tubes, the residues of the 18 front tubes will fall into the compartment ash, then
remove any residues, vacuuming everything, the residues of the 4 largest pipes
will fall into the ash collection compartment which can be accessed by removing
the 2 side caps (figure 20 - 21), a second cap is present under the external
covering (figure 22), then disassemble it and vacuum all the residues, it can be
accessed from both sides.
After having carried out all the cleaning operations, reassemble the caps with
the relative gaskets, if worn, replace them.
However, for the first few times, it is recommended to have the complete
cleaning carried out by a specialized technician.
