TOOL SPECIFICATIONS
MODEL NO. F250S-PP ( Part# 500855 )
HEIGHT 13-7/8”
WIDTH 5"
LENGTH 19-1/2"
WEIGHT 8.5 lbs.
OPERATING PRESSURE 80 to 120 p.s.i. (5.5 to 8.3 bars)
FASTENER SPECIFICATIONS
TOOL AIR FITTINGS:
This tool uses a 3/8” N.P.T. male plug. The fitting must be capable of discharging tool air
pressure when disconnected from the air supply.
OPERATING AIR PRESSURE:
80 to120 p.s.i. (5.5 to 8.3 bars). Select the operating air pressure within this range
for best tool performance.
DO NOT EXCEED THIS RECOMMENDED OPERATING PRESSURE.
NAIL LENGTH
1-1/2” and 2-1/2"
SHANK DIAMETER .131 - .162
TOOL AND FASTENER SPECIFICATIONS
NAIL COATINGS
Heat Treated,
Galvanized Heat Treated
MAGAZINE TYPE
30 Degree, Strip
