TOOL SPECIFICATIONS
MODEL NO. WCS200 (Part# 51500)
HEIGHT 11.7"
WIDTH 3.4"
LENGTH 15.1"
WEIGHT 5lbs. oz
OPERATING PRESSURE 80 to 120 p.s.i. (5.5 to 8.3 bars)
FASTENER SPECIFICATIONS
TOOL AIR FITTINGS:
This tool uses a 1/4” N.P.T. male plug. The inside diameter should be .28” (7mm)
or larger. The fitting must be capable of discharging tool air pressure when
disconnected from the air supply.
OPERATING AIR PRESSURE:
80 to 120 p.s.i. (5.5 to 8.3 bars). Select the operating air pressure within this range
for best tool performance.
DO NOT EXCEED THIS RECOMMENDED OPERATING PRESSURE.
STAPLE LENGTH 3/4"-2"
STAPLE DIAMETER 16 gauge
TOOL AND FASTENER SPECIFICATIONS
3
