BACKING PLATES & TROLLING MOTOR
Backing Plates
The diagram below shows all the screw-retention backing plates (trolling motor, T-Top, Leaning Post) originally placed in
the deck of a Pathfinder 2200 Tournament Edition during the construction process.
Trolling Motor/Wiring System
Your Pathfinder 2200 Tournament Edition comes standard with a 24V trolling motor wiring system. A trolling motor
mounting plate was built into the bow of your Pathfinder during the manufacturing process. To attach a trolling motor,
please go to your nearest Pathfinder dealer. All trolling motors should be attached by drilling through the mounting plate
with a 13/64” drill bit and 1/4” tap and using 1/4” #20 machine screws. The plate is designed to accommodate the
mounting patterns of all trolling motor brands on the market currently. See page 9 for optional trolling motor system with
battery charger and wire routing.
