Management 51
SmartNode 4950 User Manual B • Specifications
802.1p VLAN tagging
IPSEC AH & ESP Modes
Manual Key; IKE
AES/DES/3DES Encryption
Management
Web-based GUI
Industry standard CLI with local console (RJ-45, RJ-231, 9600 bps, 8, N, 1) and remote Telnet access, fully
documented
HTTP web management and firmware loading
TFTP configuration & firmware loading
SNMP v1 agent (MIB II and private MIB)
Built-in diagnostic tools (trace, debug)
Secure Auto-provisioning
System
CPU Motorola MPC8360 series operating at 266/400 MHz
Memory:
• 128 Mbytes RAM (DDR, 266MHz)
• 8 Mbytes Flash
Physical
Dimensions: 11.9W x 1.71H x 7.16D inch (302W x 44H x 182mm)
Weight: <21 oz. (<600g)
Power Consumption: < 16W
Operating temperature: 32–104°F (0–40°C)
Operating humidity: up to 90%, non condensing
