PAX Eos 100 User Manual

23
Proceed as follows to replace the two air lters: Out side air lter OA and Return air lter RA.
[1] Press up on the edge [2] Pull the lever sidways to [3] Remove the front by pulling
of the grille to open. to unlock the front panel. it down. e front panel is
secured with 6 resilient
securing hooks.
[3]
[1] [2]
[4] Pull the locking plate for OA aside. [5] Pull out the OA lter from the unit
and replace with a new one.
[5]
[4]
[7] Open cartridge and replace the Return
[6] Pull extraction cartridge down to release it. lter (RA) with a new lter.
[6] [7]
Maintenance.
Cleaning front panel
Wipe the front panel and the frame
with a damp cloth. NOTE: Do not use solvents.
Replacement air filter.
UK
Start by turning o the main switch.
