10
Environment
Operating temperature - Battery limits 0°C - 32 °F 55°C -131 °F
Weatherproof No
Communication
Ethernet network speed 10 Mbits/sec 100 Mbits/sec
Ethernet bandwidth requirement 200 kbits/sec
DHCP support Yes
RS485 network speed 115.2 kbits/sec
RS845 Dataline 3280.84 ft
(100m) between
controllers
Features
Number of Cards 100,000
Number of PINs 100,000
Access levels (per customer) 1000
Time zones 1 sec 512
Door open time 99,999 sec
Data lines per system Unlimited
Doors per controller 2
Reader ports per controller 2
Readers/ Keypads per port 2
Controllers per data line 25 (50 doors)
Data retention after total power loss 7 days
Events stored in controller with no server connection 200,000
Dimensions
Controller
4 1/64 inch (W) 4 3/4 inch (H) 1 inch (D)
Cabinet
9 1/4 inch (W) 12 1/2 inch (H) 3 1/8 inch (D)
Min Max
