Model Number
443B102
MODULAR SERIES POWER SUPPLY
Revision: F
ECN #: 47122
Performance ENGLIS
H
S
I
Sensor Input Type(s) ICP®, Charge ICP®, Charge
Voltage Gain Increment 0.1-1000 0.1-1000
Accuracy(ICP®/ Voltage Input) ± 0.5 % ± 0.5 %
Accuracy(Charge Input) ± 0.5 % ± 0.5 %
Sensitivity(ICP®/Voltage) .001 to 9.999 mV/unit .001 to 9.999 mV/unit
[11]
Sensitivity(Charge Input) 0.0001 to 10 V/pC 0.0001 to 10 V/pC
Input Range(maximum)(Charge Input) 100,000 pC 100,000 pC
[12]
Low Frequency Response(-10 %) 2.0 Hz ±20 % 2.0 Hz ±20 %
Low Frequency Response(-10 %) 0.2 Hz ±20 % 0.2 Hz ±20 %
Low Frequency Response(10 %)(Velocity) 1.0 Hz ±5 % 1.0 Hz ±5 %
Low Frequency Response(10 %)(Velocity) 10 Hz ±5 % 10 Hz ±5 %
Low Frequency Response(10 %)(Displacement) 1.0 Hz ±5 % 1.0 Hz ±5 %
Low Frequency Response(10 %)(Displacement) 10 Hz ±5 % 10 Hz ±5 %
High Frequency Response(-10 %) 200 kHz ±5 % 200 kHz ±5 %
Filter Type(4-pole Butterworth) Low Pass Low Pass
Electrical Filter Roll-off 80 dB/decade 80 dB/decade
High Frequency Response(-10 %) 0.1 kHz ±5 % 0.1 kHz ±5 %
High Frequency Response(-10 %) 1.0 kHz ±5 % 1.0 kHz ±5 %
High Frequency Response(-10 %) 3.0 kHz ±5 % 3.0 kHz ±5 %
High Frequency Response(-10 %) 10 kHz ±5 % 10 kHz ±5 %
High Frequency Response(-10 %) 30 kHz ±5 % 30 kHz ±5 %
High Frequency Response(-10 %) 100 kHz ±5 % 100 kHz ±5 %
Fault/Bias Monitor LEDS Fault/Overload Fault/Overload
Drift <0.03 pC/s <0.03 pC/s
[13]
Control Interface
Human Interface Keypad Keypad
Display 2 rows, 16 columns 2 rows, 16 columns
Digital Control Interface RS-485 RS-485
[1]
Digital Control: Data Rate 9600 bps 9600 bps
Digital Control: Start, Data, Stop, Parity 1, 8, 1, No 1, 8, 1, No
Environmental
Temperature Range(Operating) 32 to 120 °F 0 to +50 °C
Electrical
Power Required(VDC) +15 at 230 mA +15 at 230 mA
Power Required(VDC) -15 at 140 mA -15 at 140 mA
Power Required(Watts) 6.25 6.25
[2]
Power Required(VDC)
+28 at 5 mA + Sensor
Current
+28 at 5 mA + Sensor
Current
Excitation Voltage(To Sensor) 24 ±1 VDC 24 ±1 VDC
DC Offset <50 mV <50 mV
Constant Current Excitation(to Sensor, Selectable) 0 to 20 mA 0 to 20 mA
[3]
Output Voltage >±10 V >±10 V
[4]
Output Impedance <1 Ohm <1 Ohm
Broadband Electrical Noise(1 Hz to 10 kHz)(ICP® INPUT) 9 µV -101 dB
[5][6]
Broadband Electrical Noise(2 to 22.4 kHz)(ICP® INPUT) <3 µV <-110 dB
[5][6]
Spectral Noise(1 Hz) 1 µV/√Hz -120 dB
[6]
Spectral Noise(10 Hz) 0.22 µV/√Hz -133 dB
[6]
Spectral Noise(100 Hz) 0.08 µV/√Hz -142 dB
[6]
Spectral Noise(1 kHz) 0.08 µV/√Hz -142 dB
[6]
Spectral Noise(10 kHz) 0.07 µV/√Hz -143 dB
[6]
Broadband Electrical Noise(1 Hz to 10 kHz)(Charge Input) 9 µV -101 dB
[7][8]
Broadband Electrical Noise(2 Hz to 22.4 kHz)(Charge Input) <5 fC <5 fC
[7][8]
Spectral Noise(1 kHz) 0.8 µV/√Hz -122 dB
[7]
Spectral Noise(10 kHz) 0.20 µV/√Hz -134 dB
[7]
Spectral Noise(100 kHz) 0.08 µV/√Hz -142 dB
[7]
Spectral Noise(1 kHz) 0.08 µV/√Hz -142 dB
[7]
Spectral Noise(10 kHz) 0.07 µV/√Hz -143 dB
[7]
Oscillator(pC RMS) 100±1% 100±1%
Oscillator(V RMS) 1±1% 1±1%
Oscillator(Hz) 159.2±1% 159.2±1%
Time Constant(Long TC Mode) Up to 100,000 Up to 100,000
[9][10]
Time Constant(Med TC Mode) 10, 100, 1,000 ±20% 10, 100, 1,000 ±20%
Overload Threshold ± 10 V to ± 1 V ± 10 V to ± 1 V
Physical
Electrical Connector(Input, sensor) BNC BNC
Electrical Connector(Output) BNC BNC
Electrical Connector(Ext Zero) SMB SMB
Size (Height) 5.05 x 3.6 in 128 x 92 mm
[14]
Weight 1.45 lb 0.66 kg
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
ICP
®
is a registered trademark of PCB Group, Inc.
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
NOTES
:
[1] Must be used with PCB 440 series mainframe chassis with computer control (R
S
-232)
.
[2] Maximum number of 443B102 Dual Mode Signal Conditioners that can be powered by (1)
441A101 is
(
4
)
. Other modules must be calculated not to exceed total power of 30 watts
.
[3] Discrete mA settings (0, 2, 4, 8, 12, or 20).
[
4
]
In medium time constant mode, out
p
ut ran
g
e is limitied to ±8V for certain
g
ain settin
g
s
[5] Measured at gain of 1,000 (60 dB), input referred.
[6] Measured at gain of 1 with low noise ICP® simulator. (High pass filter = 0.2Hz)
[7] Measured at gain of 1 mV/pC with 1 nF source capacitance
.
[8] Measured at gain of 10V/pC (80 dB) with 1 nF source capacitance, input referred.
[
9
]
De
p
ends on
g
ain settin
g
. LCD dis
p
la
y
s value when
g
ain is entered
.
[10] When in ICP® mode, long TC is true DC response.
[11] 4 Digit - Selectable
[12] Can be increased using optional external 472B series charge attenuator
.
[13] Long time constant charge mode only.
[14] Double width unit
.
SUPPLIED ACCESSORIES:
Model 070A02 Scope input adaptor (10-32 jack to BNC plug)
Model EE-79 443B Control Software (1 CD ROM)
Entered: LK Engineer: CP
H
Sales: WD
C
A
pproved: D
Y
Spec Number:
Date: 1/29/2018 Date: 1/29/2018 Date: 1/29/2018 Date: 1/29/2018
14471
