1
1
2
2
3
3
4
4
A A
B B
CODE
IDENT. NO.
52681
DWG. NO.
SCALE: SHEET
DRAWN CHECKED ENGINEER
TITLE
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN MILLIMETERS
[ IN BRACKETS ]
ANGLES 2 DEGREES
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DIMENSIONS IN INCHES
ANGLES 2 DEGREES
FILLETS AND RADII
.003 - .005
FILLETS AND RADII
0.07 - 0.13
OUTLINE DRAWING
72786
1 OF 12.5X
012AXX SERIES & 012ACXXXAC SERIES
COAXIAL CABLE W/ BNC PLUG
DECIMALS XX ±.03
XXX ±.010
DECIMALS X ± 0.8
XX ± 0.25
NJF
02/18/20
NJF
02/18/20
BAM
02/18/20
SCHEMATIC DIAGRAM
SHELL
CENTER
PIN
7
2
7
8
6
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
REVISIONS
REV DESCRIPTION DIN
A ADDED CONNECTOR TO OPPOSITE END 50504
CABLE LENGTH TOLERANCE
LENGTH TOLERANCE
1"-11"
+1"/-0"
1'-4'
+4"/-0"
5'-99'
+6"/-0"
99'+
+1'/-0"
1
1
LENGTH WILL VARY IN FEET OR METERS DEPENDING ON THE MODEL
.54 [13.8]
LENGTH
1
012-AC:
BNC PLUG
012 CABLE:
COAXIAL CABLE W/ BLACK PVC JACKET
