2: Mainboard Installation
Jumper JP1: Keyboard Power On Selector
If you enable the keyboard power on feature, you can use hot keys
on your keyboard as a power on/off switch for the system.
Note: The system must provide 1A on the +5VSB (+5V Standby)
signal before using the Keyboard Power On function.
Function Jumper Setting
Disable Keyboard Power On Short Pins 1-2
Enable Keyboard Power On Short Pins 2-3
Jumper JA1 & JA2: CPU Selector
This jumper helps you to select the type of CPU.
Function JA1 Jumper Setting JA2 Jumper Setting
Athlon XP Short Pins 2-3 Short Pins 1-2
Other Short Pins 1-2 Short Pins 2-3
