Mainboard User’s Manual
Key Features
The key features of this mainboard include:
Socket-462 Processor Support
¨ Supports AMD Athlon XP/Athlon/Duron processors
¨ Supports 200/266 MHz Front-Side Bus
Processors are automatically configured using firmware and a
synchronous Host/DRAM Clock Scheme.
Memory Support
¨ Two DIMM slots for 168-pin SDRAM memory modules
¨ Support for 100/133 MHz memory bus
¨ Maximum installed memory is 2 x 512MB = 1GB
Expansion Slots
¨ One AMR slot for a special audio/modem riser card
¨ One optional AGP4X slot for AGP 2.0-compliant interface
¨ Two 32-bit PCI slots for PCI 2.2-compliant bus interface.
Onboard IDE channels
¨ Primary and Secondary PCI IDE channels
¨ Support for PIO (programmable input/output) modes
¨ Support for Multiword DMA modes
¨ Support for Bus Mastering and Ultra DMA 33/66/100
modes
Power Supply and Power Management
¨ ATX power supply connector
¨ ACPI and previous PMU support, suspend switch,
keyboard power on/off
¨ Supports Wake on Modem, Wake on LAN and Wake on
Alarm
