1: Introduction
Built-in Graphics System
¨ Onboard 128-bit 2D/3D 100MHz Host interface AGP
Graphics Accelerator Complies with AGP V2.0
¨ Shared memory architecture allows a maximum of 64 MB
main memory to act as frame buffer
¨ Supports high resolutions up to 1920x1440 Hi-colors, up to
2048x2048 Texture size and Virtual screen up to
4096x4096
¨ Supports hardware DVD Accelerator
AC’97 Codec
¨ Intel AC’97 v2.2 specification compatible
¨ Supports 16-bit ADC and DAC as well as stereo full-duplex
codec
¨ Supports 4 channel DAC for 4 channel speaker-out
Onboard I/O Ports
¨ Provides PC99 Color Connectors for easy peripheral device
connections
¨ Floppy disk drive connector with 1Mb/s transfer rate
¨ One serial port with 16550-compatible fast UART
¨ One parallel port with ECP and EPP support
¨ Two USB ports and optional two USB ports module
¨ Two PS/2 ports for keyboard and mouse
¨ One infrared port connector for optional module
Hardware Monitoring
¨ Built-in hardware monitoring for CPU & System
temperatures, fan speeds and mainboard voltages
Built-in Ethernet LAN
¨ Built-in 10BaseT/100BaseTX Ethernet LAN
¨ LAN controller integrates Fast Ethernet MAC and PHY
compliant with IEEE802.3u 100BASE-TX, 10BASE-T and
ANSI X3.263 TP-PMD standards
¨ Compliant with ACPI 1.0 and the Network Device Class
Power Management 1.0
¨ High Performance provided by 100Mbps clock generator
and data recovery circuit for 100Mbps receiver
