Section 5
SPECI FI CATI ONS
Display: 6 digits, 18mm high LCD or LED displays
Membrane: Polyester, tactile action.
Enclosure: Splash proof, 165mm x 110mm x 60mm High Grade Stainless Steel.
Operating Temperature: -10 to + 40 degrees C
Load cell Capabilit y: Up t o 8 x 300R load cells
Conversion: 24bit Sigma Delta A-D.
I nput Range: 0 – 150mV
Linearity: 0.0015% F.S.
Temperature Drift: 2 p.p.m per degree C
Update Speed: 7ips or 30ips – user selectable
I nternal Resolution: 300,000 counts for 10mV input (2mV per volt load cell)
Calibration: Keyboard rout ine.
Power ( Mains Option) : Mains version: 75-250vac 50/ 60Hz Auto Selection.
Power ( D.C. Option) : 6-26vdc
Power Consumpt ion: LCD version operating 10mA, LED version operating 130mA. (add 16mA per 300R
load cell)
