c. SETTI NG UP: SERI AL CONNECTI ONS - Print er
GD
Signal Ground
OP
RS232C Output
I P
RS232C Input (Busy)
Serial Protocol
RS232C (+ / - 10v)
8 Data Bits
1 Stop Bit
No Parity
Baud Rate: Selectable
ASCI I
Printer Requirements:
40 column RS232C compatible.
Common Connections (typical example 25pin D Type – Epson LX300)
Pin 3 (RXD) to OP
Pin 7 ( SG) to GD
Pin 20 (DTR/ Busy) to I P
Please refer to the printer manual for relevant pin descriptions/ terminations.
D1. SETTI NG UP: SERI AL CONNECTI ONS - PC Out put ( t ype 1 )
( For details of Hyper-terminal Mode please consult manual G8-WI NDHT-120603)
02 1 2 3 4 5 6 DP K G 0A
O
D
02 = Start
6 digits weight plus placed decimal point (data MSD to LSD)
Units i.e. kg, g, or te
0A = line feed
0D = Carriage return
D2. SETTI NG UP: SERI AL CONNECTI ONS - PC Output (type 2)
02
N/ G
S/ U
+ / -
1
2
3
4
5
6
DP
K
G
0A
OD
03
02 = Start Message
N/ G = Net t or Gross
S= Stable U= Unstable
+ / - = polarity
6 digit s weight plus placed decimal point (data MSD to LSD)
Units i.e. kg, g, or te
0A = line feed
0D = Carriage return
03 = End of message
e. SETTI NG UP: TI ME AND DATE
Restore power whilst holding PRINT key pressed.
Release the POWER key.
Input 2 digits day/ month/ year/ hour/ minute each entry followed by MODE.
For Example: < M= Mode key> 12M06M03M11M30M = 12/06/03 11:30am.
Unit automatically returns to weighing mode.
