PDA PRO-RANGE AMPLIFIERS AND MOUNTING KITS
PDA200/2 200m
2
free-standing professional induction loop amplifier
PDA500/2 500m
2
free-standing professional induction loop amplifier
PDA1000/2 900m
2
free-standing professional induction loop amplifier
PDA/WM Wall mounting kit for PDA200/2, 500/2 or 1000/2 amplifier
PDA/RM 19"Rack mounting kit for PDA200/2, 500/2 or 1000/2 amplifier
INDUCTION LOOP CABLE - see page 6 for further information
LOOP1/B 100m reel 0.5mm
2
single core black loop cable
LOOP1/W 100m reel 0.5mm
2
single core white loop cable
LOOP2/B 100m reel 1.0mm
2
single core black loop cable
LOOP2/W 100m reel 1.0mm
2
single core white loop cable
LOOP3/B 100m reel 1.5mm
2
single core black loop cable
LOOP3/W 100m reel 1.5mm
2
single core white loop cable
LOOP4/B 100m reel 2.5mm
2
single core black loop cable
LOOP4/W 100m reel 2.5mm
2
single core white loop cable
FLAT1005 100m x 0.5mm
2
insulated copper tape (flat loop cable for under carpets)
FLAT2005 100m x 1.0 mm
2
insulated copper tape (flat loop cable for under carpets)
FLAT3005 100m x 1.5mm
2
insulated copper tape (flat loop cable for under carpets)
TAPE 50m white synthetic fibre tape (used to protect flat loop cable)
OUTREACH PLATES - see page 7 for further information
APM Omni-directional plated microphone, for wall/ceiling/desk mounting
APL Double phono line level outreach plate
APJ 3.5mm mono jack mic. level outreach plate
APQM 6.35mm jack mic. level outreach plate
APQL 6.35mm jack line level outreach plate
APXM XLR 3 pin mic level outreach plate
APXL XLR 3 pin line level outreach plate
API AFILS active indicator light
BELDEN/10 10m Belden 8723 four core screened cable for use with outreach plates
BELDEN/25 25m Belden 8723 four core screened cable for use with outreach plates
INDUCTION LOOP TESTING EQUIPMENT - see page 13 for further information
PNGN Pink noise generator
(requires PP3 battery and AL3 connection lead)
AHHM FoSmeter magnetic field strength meter
(requires PP3 battery)
AMPN FoSmeter Plus combined pink noise generator & magnetic field strength meter
(requires PP3 battery and AL3 connection lead)
AHHM/H FoSmeter H combined magnetic field strength meter & loop listener
(requires HEAD1 32 Ohm headphones)
HEAD1 32 Ohm headphones for use with AHHM/H
AL3 3.5mm jack to bare ended lead
(connects PNGN or AMPN to a pro-range amplifier’s outreach socket)
INDUCTION LOOP ANCILLARIES
APT Loop connector plate (for the termination of induction loop cable)
LEST 100V line (i.e PA system output) to 0db (775mV line level) convertor
TEAR10 Pack of 10 self-adhesive ‘induction loop in use’ stickers
