3
Always turn the Inverter ON/OFF switch to the OFF position, disconnect the battery clips from the •
battery or power source, and disconnect the 12-volt power plug from the 12-volt cigarette lighter/
accessory socket when not in use to avoid draining the battery.
Always remove the appliance plug from the AC receptacle before working on the appliance. •
Only connect the power plug to the 12-volt cigarette lighter/accessory socket when the vehicle is •
parked. Do not connect the power plug while driving the vehicle.
Do not insert foreign objects into the AC receptacles.•
INTRODUCTION
This Power Inverter can be used to operate household appliances (TVs, VCRs, DVD players) and
personal electronic devices (laptop and desktop computers, MP3 players, cell phones) with a normal
power requirement of up to 400 continuous watts using the 12-volt battery connection. The 12-volt
power plug is capable of delivering up to 140 continuous watts when connected to the vehicle’s
12-volt cigarette lighter/accessory socket.
When using the Power Inverter in a vehicle, check the vehicle’s owner’s manual for maximum •
power rating and recommended output.
Read and understand this Instruction Manual before using the Power Inverter.•
Install and operate the Power Inverter only as described in this Instruction Manual.•
FEATURES
Compact design for safer use, transport and storage•
Connects to either a 12-volt cigarette lighter/accessory socket or a 12-volt battery•
Two North American Standard 120-volt AC receptacles•
LED operation indicators•
ON/OFF switch•
Low battery alarm•
Mounting brackets for solid mounting•
1 2 3
4
5
7
8
6
Legend
Green LED Power Indicator 1.
Red LED Fault Indicator2.
ON/OFF Switch3.
North American Standard 120-volt 4.
AC Receptacles (2)
Mounting Brackets5.
Cooling Fan6.
Red Positive (+) Screw Connector7.
Black Negative (-) Screw Connector8.
12-volt Cigarette Lighter/Accessory Socket 9.
Power Plug and Harness
Battery Clips and Harness10.
9
10
