5.4. AC Voltage Measurement
1. Connect the black test lead to the COM jack and the red test
lead to the V/Ω/ mA-jack.
2. Set function switch to the AC V range to be used and connect
the test leads across the source or load under measurement.
Note:
1. If the voltage range is not known beforehand set the function
switch to the highest range and work down.
2. Caution: Do not apply more than 600 V
rms
to the input.
Indication is possible at higher voltages but there is danger of
damaging the internal circuitry.
3. Use extreme caution to avoid contact with high tension circuits
when measuring high voltage.
5.5. DC Current Measurement
1. Connect the black test lead to the COM jack and the red test
lead to the V/Ω/ mA-jack for a max. of 200 mA. For a maximum
of 10 A, move the red test lead to the 10 A jack.
Set the function switch to the DC A range to be used and
connect the test leads in series with the load under
measurement.
Note:
1. If the current range is not known beforehand, set the
FUNCTION switch to the highest range and work down.
2. When only the figure "OL" is displayed overrange is being
indicated and the FUNCTION switch must be set at higher
range.
-23-
