PeakTech 1035 User Manual

CAUTION!
Note on using the supplied safety test leads according the IEC /
EN 61010-031:2008:
Measurements in the field of overvoltage category CAT I or CAT II
can be performed with test leads without sleeves with a maximum of
up to 18mm long, touchable metallic probe, whereas for
measurements in the field of overvoltage category CAT III or CAT IV
test leads with put on sleeves, printed with CAT III and CAT IV must
be used, and therefore the touchable and conductive part of the
probes have only max. 4mm of length.
3. Specifications
Accuracies are: (% of reading + no. of digits) guaranteed for 1 year,
23° C ± 5° C, less than 75 % R.H.
DC Voltage
Range
Accuracy
Resolution
200 mV
± 0.5 % + 2 digit
100 µV
2000 mV
1 mV
20 V
10 mV
200 V
100 mV
600 V
1 V
Input Impedance: > 1 MΩ on all ranges
Overload protection: 600 V DC or peak AC
rms
on all ranges,
in 200 mV range 220 V
rms
AC Voltage
Range
Accuracy
Resolution
200 V
± 1.2 % + 10 digit
100 mV
600 V
1 V
Input Impedance: > 1MΩ on all ranges
Frequency range: 45 Hz to 450 Hz
Overload protection: 600 V DC or AC
rms
in all ranges
Indication: Average (rms of sine wave)
-18-

PeakTech 1035 Specifications

General

Product type	Digital multimeter
DC voltage range	600 V
Resistance range	0.1 - 2000 Ω
Battery test mode	Yes
Measuring category	CAT III 600V
Placement supported	Handheld multimeter
Battery test mode range	1.5 - 9 V
Resolution (AC voltage)	100 mV
Resolution (DC current)	2000 µA
Resolution (DC voltage)	200 mV
Basic accuracy (DC current)	+/- 0.5%
Battery type	9V
Power source	Battery
