Note:
1. When the input is not connected, i. e. at open circuit, the
figure "OL" will be displayed for the overrange condition.
2. There is 1 mA current flow through the device under test
3. The meter displays the forward voltage drop in millivolts,
and overload when the diode is reversed.
5.8. Battery test function
With this function you can test batteries with a load in form of a
resistance, resulting in a more accurate assessment of the battery
power as in the pure tension test.
This measurement function is not suitable for testing of button cells,
because they are not designed for high load.
Load ranges
1,5 V/13,4 for AAA/UM4 & AA/UM3 batteries
9 V/1,4 k for 9V (NEDA 1604, 6F22, 006P) batteries
WARNING!
If not handled carefully, batteries and accumulators can cause by
sparks or even an explosion of the battery through a short-circuit.
Make sure that the battery poles are never shorted by metallic items.
1. Connect the black test lead into the “COM” socked and the red
test lead into the “V//mA” socket.
2. Turn the rotary switch to the battery test position 1,5 V or 9 V
range, which the nominal voltage of the test battery meets.
3. Connect both test probes to the battery to be measured.
-25-
