Caution and warning statements
CAUTION Is used to indicate correct operating or maintenance procedures in order
to prevent damage or destruction of the equipment or other property
WARNING Calls attention to a potential danger that requires correct procedures or
practices in order to prevent personal injury.
Symbols
Caution (refer to accompanying documents) and Warning
protective ground (earth) symbol
1. Introduction
Thank you for purchasing this product. This oscilloscope is a high technical product made under strict quality
control. We guarante their exceptional precision and utmost reliability. For proper use of the proudct please
read this user manual carefully.
1.1 Instructions
1. To maintain the precision and reliability of the product use it in the standard setting (temperature 10°
to 35° centigrade, humidity 45 - 85 %).
2. After turning on power, please allow a 20-minute pre-heating period before use.
3. Triple-line power cord is to be used for the product. But when you are using the doubleline cord,
make sure for safety.
4. For quality improvement the exterior design and specifications of the product can be changed
without prior notice.
5. If you have further questions concerning use, please contact your dealer.
1.2 Specifications
CRT
Configuration 6-inch rectangular tube with internal gratitude;
Effective Surface 8 x 10 division (1 div. = 1 cm), marking for measuring rise and fall time.
control axis is graduated in 2 mm subdivisions.
Accelerating Potential approx. +1.9 kV DC (Cathode basis)
Phosphor P31 (Standard)
Focussing possible
Trace rotation provided
Intensity Control provided
Z-Axis input (Intensity Modulation)
Input signal Positive going signal decreases intensity +5 V
pp
or more signal cases
noticeable modulation at normal intensity settings.
Band width DC-2 MHz (-3 dB)
Coupling DC
Input impedance 20 k - 30 kΩ
- 30 -
