Maximum input voltage 30 V (DC + peak AC)
Vertical Deflection
Band width (-3 dB)
DC coupled DC to 20 MHz normal (x 1)
DC to 10 MHz magnified (x 5) - only CH 1
AC coupled 10 Hz to 20 MHz normal (x 1)
10 Hz to 10 MHz magnified (x 5) - only CH 1
Modes CH1, CH2, ADD, DUAL (CHOP: Time/div switch):
0,2 s-1 ms, ALT: Time/div. switch: 0,5 ms-0.2 µs
Deflection Factor 5 mV/div to 20 V/div in 10 calibrated steps of a 1-2-5 sequence.
Continuously variable between steps at least 1:2.5
X5 MAG: 1 mV/div. to 1 V div. in 10 calibrated steps (CH 1 only)
Accuracy Normal: ± 3 %, Magnified: ± 5 % (only CH 1)
Input impedance approx. 1 MΩ in parallel with 30 pF
Maximum input voltage Direct: 400 V (DC + peak value AC)
Probe: refer to probe specification
Input Coupling DC-GND-AC
Rise Time 17.5 ns of less (35 ns or less: x 5 MAG)
CH 1 Output Termination connection 25 mV/div to 50 Ω: 20 Hz to 10 MHz (-3 dB)
Polarity Inversion CH 2 only
Horizontal Deflection
Display modes x 1, x10, VARIABLE, X
.
Y,
Time base 0,2 µs, div to 0.2 s/div in 19 calibrated steps with 1-2-5 sequence
uncalibrated continuous control of over 2.5 times is possible
Sweep Magnifications 10 times (maximum sweep rate: 20 ns/div.
Note: 50 ns/div of A Time bases are ± 10 %
Accuracy ± 3 %, ± 5 % (0° C to 40° C), ± 2% increase when magnified
Trigger System
Modes AUTO, NORM, TV-V, TV-H
Source VERT (DUAL, ALT), CH1, LINE, EXT
Coupling AC
Slope + or -
Senstivity & Frequency Range
AUTO, NORM 20 Hz - 2 MHz 20 Hz - 20 MHz
INT (VERT) 0.5 div (2.0 div) 1.5 div (3.0 div)
EXT 0.2 V
p-p
0.8 V
p-p
TV-V, TV-H at least 1 div. or 1.0 V
pp
External trigger input impdance Capactive of some 30 pF with approx. 1 MΩ in parallel
