Max. Input voltage 400 V DC + peak value AC
X-Y Operation
X-axis (Same as CH 1 except for the following)
Deflection Factor: Same as of CH 1
Accuracy: ± 5 %
Frequency Response: DC to 500 kHZ (-3 dB)
Y-axis Same as CH 2
X-Y Phase Difference 3° or less (up to 50 kHz in DC)
Component Test (PeakTech 2030 KT only)
*one test lead is grounded (safety earth
Test voltage approx. 4,5 V
rms
(open circuit)
Test current max. 6,6 mA
rms
(short circuit)
Test frequency approx. 60 Hz
Calibrator (Probe Adjustor) approx. 1 kHz ± 20 %, 0.5 V (± 10 %) square wave duty ratio:
40 ~60%
Voltage range Fuse (250 V)
UL 198 G IEC 127
115 (98 – 125 V) AC 1.25 A 1.25 A
230 (198-250 V) AC 0,63 A 0,63 A
Frequency 50/60 Hz
Power Consumption approx. 45 W
Weight/Dimension
Weight 7,8 kg
Dimension 316 mm (W) x 132 mm (H) x 410 mm (L)
Environmental Charac.
Temperature range +10° C to + 35° C (+50° F to +95° F)
for rated operation
Max. ambient operating
temperature 0° C to +40° C (+32° F to 104° F)
Max. storage temperature -20° C to +70° C (-4° F to 158° F)
Humidity range for rated
operation 45 % to 85 % RH
Max. ambient operating
humidity 35 % to 85 % RH
Safety EN 61010-1 overvoltage CAT II, degree of polution 2
Approval: TÜV/GS
EMC Interference: EN 50081-1
Susceptability: EN 50082-1, IEC801-2, 3, 4
Caution: Sources like small hand-held radio transceivers, fixed station radio and television transmitters,
vehicle radio transmitters and cellular phones generate electromagnetic radiation that may induce voltages in
the leads of a test probe in such cases the accuracy of the oscilloscope cannot be guaranteed due to
physical reasons. Using the 8 div scale, the oscilloscope radiation can be exceeded the limit.
