PeakTech 2700 User Manual

4.2. Voltage Measurements
1. Set the function switch to the highest 1000 V DC ( ) or
750 V AC (~) position.
2. Insert the black test lead banana plug into the negative COM
jack.
3. Insert the red test lead banana plug into the positive V jack.
4. Touch the black test probe tip to the negative side of the circuit.
5. Touch the red test probe tip to the positive side of the circuit.
6. Read the voltage in the display. DC/AC VOLTAGE
MEASUREMENTS: If the polarity is reversed, the display will
show (-) minus before the value
4.3. 200 k Resistance measurements
1. Set the function switch to the highest 200 k position.
2. Insert the black test lead banana plug into the negative COM
jack
3. Insert the red test lead banana plug into the positive  jack.
4. Touch the test probe tips across the circuit or part under test. It
is best to disconnect one side of the part under test so the rest
of the circuit will not interfere with the resistance reading.
5. Read the resistance in the display
-22-
