4.4. Using the Input Terminals
All functions except the current measurement function use the
V//CAP/Hz%/Temp and COM input terminals.
10A
Input for 0 A to 10.00 A current (20VA
overload for 30 seconds on, 10 minutes off)
µA mA
Input for 0 A to 600 mA current
measurements
COM
Ground-terminal for all measurements
V / Ω / /
Hz% / CAP / °C /°F
Input for voltage, continuity, resistance,
diode test, frequency, capacitance and
temperature
-53-
