PeakTech 3730 User Manual

22
3. Measuring Functions
3.1. Capacitance
Range
Resolution
Accuracy
testing frequency
2 nF
1 pF
± 1,0 % v.M. +5 St.
1 kHz/150 mV
20 nF
10 pF
200 nF
100 pF
2 µF
1 nF
± 4,0 % v.M. +5 St.
20 µF
10 nF
100 Hz/15 mV
200 µF
100 nF
600 µF
1 µF
Reference only
100 Hz/1,5 mV
Overload protection: 0,315A / 250V fuse
If the meter cannot adjust to zero, you could use the tested values
minus the open circuit value to get the correct measurement
values.
3.2. Inductance
Range
Resolution
Accuracy
Tested
Frequency/
Current
2 mH
0,001 mH
+/- 2% v.M. + 8 St.
1kHz / 150µA
20 mH
0,01 mH
200 mH
0,1 mH
2 H
0,001 H
+/- 5% v.M. + 5 St.
20 H
0,01 H
+/- 5% v.M. +15 St.
100Hz / 15µA
