10
In this way, other option data can also be adjusted by the knob ,which will not
restated again.
Setting of period of channel A Set the period to be 25ms
Perd】【2】【5】【ms
Setting of amplitude of channel A Set the amplitude to be 3.2V
Ampl】【3】【.】【2】【V
Selecting of amplitude format of channel A Virtual value or peak-peak value
pp/rms. The indicator light of Vpp means the selection of peak-peak value
of amplitude. The indicator light of Vrms means the selection of virtual value of
amplitude.
Selecting of common-used waveforms of channel A Select sine, square, triangle,
ramp for channel A
Sine】【Square】【Triang】【Ramp
Selecting of waveform of channel ASelect exponential for channel Awaveform
no.12see the table of 16 waveform sequence numbers on page 19
Wave】【1】【2】【n
Setting of duty cycle of channel A Set the duty cycle of channel A to be 65
Duty】【6】【5】【%
Setting of attenuation of channel ASet the fixed attenuation to be 0dBselect
auto attenuation, AU, after start-up or reset
Atten
】【0】【dB
Setting of offset of channel A Set the DC offset to be -1V when the attenuation is
0dB.
Offs】【-】【1】【V
Step frequency of channel ASet the step frequency of channel A to be 12.5Hz
Press the key of Menu and then press the keys of1】【2】【】【5】【Hz.
The frequency of channel A will be added by 12.5Hz at each pressing of the key of
【∧】; the frequency of channel A will be reduced by 12.5Hz at each pressing of
the key of【∨】.
1.5.2 Setting of parameters of channel B Press the key ofCHB and the
indicator lights of “CHB” and “Tone” will be on and select the function of “Single
