PeakTech 4025 User Manual

8
Table of function option
function
Frequency of
channel A
sine
Frequency of
channel B
sine
Frequency
sweeping
Frequency
modulation
Exterior
measuring
frequency
Frequency of
channel A
Frequency of
channel B
Start
frequency
Carrier
frequency
Exterior
measuring
frequency
Period of
channel A
Period of
channel B
End
frequency
Carrier
amplitude
Gate time
Amplitude of
channel A
Amplitude of
channel B
Step
frequency
Frequency
modulation
Waveform of
channel A
Waveform of
channel B
Sweeping
mode
Offset of
Frequency
modulation
Duty cycle of
channel A
Duty cycle
of channel B
Interval
time
Modulation
waveform
Attenuation of
channel A
Harmonic
waveform of
channel B
Offset of
channel A
Phase shift
of channel B
Step frequency
option
Step amplitude
1.4 Keyboard description
There are 38 keys on the front panel of the instrument with the following
functions (see the layout of the front panel).
The keys of 【0 】【1】【2】【3 】【4】【5】【6】【7】【8】【9】：To
enter the numbers.
The key of【.】：To enter the Decimal point.
The key of【-】：To enter the minus in the option of “Offset”, and in other
circumstances, it is used to enable or disable the key-press sound circularly.
The keys of 【 CHA 】【CHB 】【Sweep 】【FM 】【Count 】：Function
selection keys.
The key of 【Menu】：To select the options without shadow in the table of
function options circularly.
