3
• Do not store the meter in a place of explosive, inflammable substances
• Do not modify the equipment in any way
• Opening the equipment and service- and repair work must only be performed
by qualified service personnel
• The instrument must be set up so that the power plug can removed from the
socket easily.
• Measuring instruments don´t belong to children hands
Introduction of PeakTech
®
DDS Function Generators
With Direct Digital Synthesis Technique（DDS）, PeakTech
®
DDS function
generators are of the high performance indexes and numerous function characteristics
which are necessary for the fast completion of measuring. The simple and clear front
panel design and the display interface of number and indicator light are convenient
for the users to operate and observe. Moreover, the extended optional functions
enhance the system characteristics.
The generators are of the following advanced specifications and powerful
function characteristics.
High frequency accuracy: up to the level of 10
-5
.
High frequency resolution
: 20mHz for the whole range.
Unlimited measurement range: without limitation for the whole range, digital
setting directly.
Non-intergraded process: up to the stable value immediately when switching,
continuous signal phase and amplitude without deflection.
High waveform accuracy
: the output waveform is synthesized by the computation
value of functions with higher waveform accuracy and less distortion.
Multi-waveform: 16 types of waveforms can be output.
Square characteristics: Accurate square duty cycle can be set.
Output characteristics: Independent output for two channels, the phase
difference can be set accurately.
Frequency sweeping: Be of the function of frequency sweeping and amplitude
sweeping. Start point and end point can be set arbitrarily.
Frequency modulation:
Frequency modulation signal (FM) can be output.
Computation function: Frequency or period, amplitude virtual value or peak-
peak value can be selected.
