AAM 802/1602 COMPACT CONSOLE
Specifications:
Input Specifications:
Function Input Z Input Gain Input Levels Bal/ Connector
(ohms) Settings Min** Nominal* Max UnBal.
Min
Microphone 2.2 k Max. Gain -74 dBu -54 dBu -37 dBu Bal. XLR: Pin 1 Gnd,
(150 ohms) (58 dB) Pin 2 (+),
Min. Gain Pin 3 (-)
(10 dB) -27 dBu -6 dBu +10 dBu
Line Input 10 k Max. Gain -54 dBu -34 dBu -17 dBu Bal. 1/4" TRS; Tip (+),
(10 k ohms) (38 dB) Ring (-),
Sleeve Ground
Min. Gain -6 dBu +14 dBu +31 dBu
(-10 dB)
Insert 10 k N/A -16 dBu +4 dBu +22 dBu Unbal. 1/4" TRS; Tip Send,
Return (0) dB) Ring Return,
Sleeve Ground
Stereo Line 10 k Max. Gain -26 dBu +4 dBu +22 dBu Unbal. 1/4" TS; Tip (+),
Input (30 dB) Sleeve Ground
Aux Returns 10 k N/A -26 dBu +4 dBu +22 dBu Unbal. 1/4" TS; Tip (+)
(0 dB) Sleeve Ground
Tape 10 k N/A -26 dBu -10 dBV +12 dBu Unbal. RCA Phono
(10 dB)
0 dBu=0.775 V (RMS)
** Min. input level (sensitivity) is the smallest signal that will produce nominal output (+4 dBu) with channel and master
level controls set for maximum gain.
* Nominal settings are defined as all controls set a 0 dB (or 50% rotation for rotary pots) except the gain adjustment pot,
which is as specified.
