12
Footswitch
CHANNEL SWITCH
Toggles between the Clean channel and the Crunch channel.
EFFECTS LOOP ON/OFF SWITCH
Toggles the Effects Loop on or off. When the indicator light is lit, the Effects Loop is active.
CLEAN CHANNEL BOOST
Switches on the preamp boost on the Clean channel.
REMOTE CABLE JACK
Connect the included eight-pin cable to the amp's footswitch/MIDI input jack.
Note: You must use the included eight-pin cable, as it supplies the footswitchwith power. When using an external
MIDI source to control the amplier, a ve-pin MIDI cable can be used. Since the Butcher uses MIDI control,
changes made to switches on the amplier will be reected by the LED's on the footswitch, and vice versa.
CRUNCH CHANNEL BOOST
Switches on the preamp boost on the Crunch channel.
MASTER VOLUME SELECT SWITCH
Toggles between the Two Master Volume controls.
1
2
3
4
5
6
1 2 3 4 5
6
