SPEAKER OUTPUTS

These paralleled 1/4" mono (TS) jacks are provided for the connection of speaker enclosure(s). Minimum

speaker impedance is 4 ohms. The CABINET IMPEDANCE SWITCH (7) should be set to match the load of the

speaker cabinet(s).

HALF POWER SWITCH

The Butcher is equipped with a half-power switch that reduces the maximum output power from 100 watts to

50 watts. 50-watt ampliers have a different character than 100 watt ampliers, overdriving more quickly and

at slightly lower volumes. This switch is available for you to determine your own personal preferences and can

be a versatile tool in the studio as well. The CABINET IMPEDANCE SWITCH (7) should be set to match the load

of the speaker cabinet(s), as the settings will be different for half-power mode.

IEC MAINS CONNECTOR

This is a standard IEC power connector. An AC mains cord having the appropriate AC plug and ratings for the in-

tended operating voltage is included in the carton. The mains cord should be connected to the amplier before

connecting to a suitable AC outlet.

U.S DOMESTIC AC MAINS CORD

The mains cord supplied with the unit is a heavy-duty, 3-conductor type with a conventional 120 VAC plug with

ground pin. If the outlet used does not have a ground pin, a suitable grounding adapter should be used, and

the third wire should be grounded properly.

Never break off the ground pin on any equipment. It is provided for your safety.

NOTE: FOR UK ONLY

If the colors of the wires in the mains lead of this unit do not correspond with the colored markings identifying

the terminals in your plug, proceed as follows: (1) The wire that is colored green and yellow must be connected

to the terminal that is marked by the letter E, the Earth symbol, colored green, or colored green and yellow. (2)

The wire that is colored blue must be connected to the terminal that is marked with the letter N or the color

black. (3) The wire that is colored brown must be connected to the terminal that is marked with the letter L or

the color red.

FUSE

A fuse is located within the cap of the fuse holder. This fuse must be replaced with one of the same type and

value to avoid damaging the amplier and voiding the warranty. If the amp repeatedly blows the fuse, it should

be taken to a qualied service center for repair.

WARNING: THE FUSE SHOULD ONLY BE REPLACED AFTER THE POWER CORD HAS BEEN DISCONNECTED.
