13
Series Specications
Power Amplifier Section:
Power @ Clipping (Typically):
(1 kHz, 120 VAC line)
40 W RMS into 6 Ω
Frequency Response:
+0, -2 dB 100 Hz to 20 kHz @ 35 W
RMS into 6 Ω
Hum and Noise:
Greater than 86 dB below rated
power
Power Consumption:
(Domestic)
75 W @ 60 Hz, 120 VAC
(Export)
75 W @ 50/60 Hz, 220-240 VAC
Preamp Section:
The following spec are measured @
1 kHz with the controls preset as
follows:
Channel Select, Clean
Clean Mode Switch, Modern
Low and High @ 10
Mid @ 0
Lead Pre and Post Gain @10
Lead Mode Switch, Vintage
Reverb @ 0
Nominal Levels are with Clean
Volume @ 5
Minimum Levels are with
Clean Volume @ 10
Headphone Output:
Load Impedance: 16 Ω or greater
0.3 W RMS
System Hum & Noise @
Nominal Input Level:
(20 Hz to 20 kHz unweighted)
Greater than 78 dB below rated power
Speaker Simulated Direct
Output Level:
0.4 V RMS Nominal
Equalization:
Special Low, Mid, and High passive
type EQ.
Modern/Vintage switch (Clean):
Two distinct EQ voicings.
Vintage/Modern/High Gain switch (Lead):
Three different EQ and Gain voicings
External Footswitch Functions:
Clean or Lead channel selection
and volume Boost
Dimensions (H x W x D):
17" x 19.375" x 9.250"
43.18 cm x 49.21 cm x 23.46 cm
Weight:
24.5 lbs (11.13 kg)
Envoy® 110
Features and specifications subject to change without notice.
