Fig. 6
4. After completion, it can be rackmounted into
an EIA standard rack case. Shown in figure 7.
5. Make sure that the system performs correctly
by placing the system away from noise
sources. Place the receiver at least one meter
above the ground and one meter away from
noise sources. Place the microphone at least
one meter away from the receiving antenna,
as shown in figure 8.
Fig. 7 Fig. 8
9
