Crosstalk/Attenuation
Dimensions
Meters
Weight
Signal/Overload Indicators
Power Requirements
Common Mode Rejection Ratio (Mic Input)
Adjacent Input Channels (1 kHz) >90 dB Mute Button Attenuation (1 kHz) >90 dB
Left to Right Outputs (1 kHz) >70 dB Channel Fader Kill (1 kHz) >85 dB
16.1875" wide x 17.3" deep x 2.1875" high
(41.12 cm wide x 43.94 cm deep x 5.56 cm high)
PV14BT: 12.12 lbs (5.50 kg) 100-240 VAC 50/60 Hz 24 Watts
PV14AT: 12.16 lbs (5.52 kg)
12 segment, peak reading (top green LED = +4 dBu) Red LED lights 5 dB below clipping
50 dB minimum (20 Hz to 20 kHz)
70 dB typical @ 1 kHz
