19
XR684F · Product Weight and Dimensions:
Width: 19" Height: 10.75" Depth: 11" Weight: 36.000 lbs
XR696F · Product Weight and Dimensions:
Width: 19" Height: 10.75" Depth: 11" Weight: 41.700 lbs
XR696F · Power Amplifier Specifications:
Power Section:
1200 SC Module with DDT
Rated Power:
600W program into 4 ohms‚ both
channels driven/500W RMS into 4
ohms‚ both channels driven
475W program into 8 ohms‚ both
channels driven/360W RMS into 8
ohms‚ both channels driven
Frequency Response:
20Hz–20kHz +0dB‚ -1dB @ rated
power
Total Harmonic Distortion (THD):
<0.01% @ rated output @ 1kHz
DDT Dynamic Range:
Greater than 26dB
DDT Maximum Distortion:
Below 0.5% THD for 6dB overload
Below 1% THD for 20dB overload
Hum and Noise:
97dB below 500W
Damping Factor:
Greater than 100 @ 1kHz‚ 4 ohms
Input Sensitivity:
1.5 V RMS for 500W @ 4 ohms
Input Impedance:
8.25k ohms
Power Requirements:
500W‚ 120 VAC‚ 60Hz
