Pecron DC1242-500 - Function Introduction; XT90 Input Connector; Starting Voltage Knob; Output Port

FUNCTION INTRODUCTION
BASIC PARAMETERS
DC 1242-500
12~30V, 50A(MAX)
42V, 13A(MAX)
100A
Up to 500W
About 0.1mA under shuntdown model and 260mA under state of power-on but
without any load.
-10℃~55℃ / 14℉~131℉
10℃~45℃ / 50℉~113℉
Fan cooling
Short-circuit protection, over-voltage protection, under-voltage protection,
overheating protection.
193*90*52 mm / 7.6*3.5*2 in
12 months
Product Model
Input Specification
Output Specification
Fuse Rated Current
Output Power
Standby power
Operating Temperature
Storage Temperature
Heat Dissipation
Protective design
Dimension
Warranty
①
②
③
④
⑤
⑥
①
②
XT90 Input
Heat Sink
③
④
Starting Voltage Knob
Switch Button
⑤
⑥
Heat Sink
Output
