peerless-AV XTREME XHB432-EUK - Page 43

43
2018-08-10 #:180-9120-2 (2019-01-10)
Préparer le A󰀩chage au Montage
Pièce A B C D E F
XHB432-EUK
39.50"
(1003mm)
23.28"
(591mm)
37.06"
(941mm)
20.84"
(529mm)
42.51"
(1080mm)
0.33"
(8mm)
XHB492-EUK
44.72"
(1136mm)
26.22"
(666mm)
42.27"
(1074mm)
23.78"
(604mm)
48.50"
(1232mm)
0.33"
(8mm)
XHB552-EUK
50.07"
(1272mm)
29.23"
(742mm)
47.62"
(1210mm)
26.79"
(680mm)
54.64"
(1388mm)
0.42"
(11mm)
1.51"
(38mm)
1.22"
(31mm)
1.22"
(31mm)
C
A
B D
E
F
VUE DE FACE
VUE DÉTAILLÉE DU CADRE/IR
