PEERLESS PARAMOUNT PT640 - Included Parts List; Adapter Bracket Fastener Details

3 of 24
ISSUED: 10-31-07 SHEET #: 202-9242-2 03-20-08
Visit Peerless website at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870
CCAA BB
DD
EE
M4 x 12 mm (4)
504-9013
M4 x 25 mm (4)
504-1015
M5 x 12 mm (4)
520-1027
M5 x 25 mm (4)
520-9543
M6 x 12 mm (4)
520-1128
M6 x 25 mm (4)
520-1208
M6 x 20 mm (4)
520-9402
M6 x 30 mm (4)
510-9109
Adapter Bracket Fasteners
I.D. .26" (6.5 mm ) (4)
540-1058
I.D. .205" (5.2 mm) (4)
540-1040
Parts may appear slightly different than illustrated.
Qty. Part #
AA
wall plate 1 200-P1797
BB
1 201-P1465
CC
1 201-P1467
DD
4 5S1-015-C03
EE
4 590-0097
Parts List
Description
Before you begin, make sure all parts shown are
included with your product.
alligator
®
anchor
left adapter bracket
right adapter bracket
#14 x 2.5" wood screw
