PEERLESS PureFire PF-80 - Page 73

71
REPAIR PARTS
Table 13.1: General Repair Parts
Description
Quantity
Required
Stock
Code
1 Front Door Panel with Ball Studs 1 54168
2 Control Lens 1 54167
3 Display Module Revision 2 852RC-3R 1 54423
4 Display Bracket Gasket 1 54153
5 Bracket for Display Module 1 PF2007-1
6 Hex Nut, #6-32 with Lockwasher 2 51553
7 Screw, #6-32 x 1/2" LG Phillips Head 2 5449
8 Flexible Gas Line – 1/2" (includes gasket and hardware) 1 54203
9 Gasket for Gas Line 1 54142
10 Nipple, 1" NPT x Close 1 99211
11 Manual Shut-off Valve, 1/2" NPT 1 54130
12 Screw, #10 x 1/2" Long Hex. Hd. 2 99992
13 Coupling, 1" NPT Brass 2 5534
14 Nipple, 1" NPT x 6" Long Brass 2 5533
15
Jacket Side Panels – PF-50, PF-80 1 54173
Jacket Side Panels – PF-110, PF-140 1 54192
17 Bulk Head Fitting for Condensate Connection 1 54140
18 Gasket for Bulk Head Fitting 1 54134
19 Leg Leveler 4 5429
20 Hook Bolt 2 5451
21 Convenience Outlet 1 54136
22 Hex. Nut, #8-32 with Lockwasher 4 51573
23
Control Module, 852MN Kit – PF-50 Revision 1 & 2 1 54282
Control Module, 852MN Kit – PF-80 Revision 1 & 2 1 54283
Control Module, 852MN Kit – PF-110 Revision 1 & 2 1 54284
Control Module, 852MN Kit – PF-140 Revision 1 & 2 1 54285
24 Switch, Round Toggle, 120 VAC 1 6049
25 Vent / Air Inlet Adapter, 3" 1 54135
26 Gasket, Vent Adapter, 3" 1 54133
27 Screw, #10 x 5/8" Long Phil. Pan Head Type A Zinc 6 5507
28 Condensate Receiver Kit 1 54205
29 Condensate Neutralizer Kit 1 54204
– Wiring Harness, Power (Right Terminal Block) 1 PF7002
– Wiring Harness, Control (Left Terminal Block) 1 PF7003
– Wiring Harness, Blower 1 PF7005
– Wiring Harness, Ground Wire 1 PF7009
– Push-on Terminal Block (for Field Wiring Connections) 2 5450
– Ignition Cable 1 54115
– Relief Valve 1 50664
– Flue Sensor, 12kOhm Tasseron TSDZ0B1 1 54111
– Supply Sensor/Switch, 12kOhm Tasseron Kit 1 54299
– Return Sensor, 12kOhm Tasseron TSD00BS 1 54418
– Outdoor Sensor, 12kOhm Tasseron TSA00B4 1 54112
– DHW Sensor, 12kOhm Tasseron TSK10BH (Optional) — 54157
– System Sensor, 12kOhm Tasseron TSA00BC (Optional) — 54156
