REPAIR PARTS
Table 13.4: Heat Exchanger/Burner Assembly Repair Parts – PF-210 & PF-399
Description
Quantity
Required
Stock
Code
1 Ignitor, with Gasket 1 54246
2 Sensor, with Gasket 1 54247
5
Premix Channel – PF-210 1 54249
Premix Channel – PF-399 1 54250
6 Gasket, Channel to Burner 1 54186
7
Burner – PF-210 1 54263
Burner – PF-399 1 54264
9 Combustion Chamber Cover Plate, includes items #10-#12 1 54248
10 Gasket, Glass Rope 1 54188
11 Gasket, Rubber 1 54187
12 Insulation, Combustion Chamber Cover Plate 1 54255
15 Insulation, Target Wall 1 54185
16
Heat Exchanger – PF-210 1 5529
Heat Exchanger – PF-399 1 5530
17 Gasket, Blower to Channel 1 54122
18
Blower – PF-210 1 54258
Blower – PF-399 1 54257
20
Blower Adapter Plate – PF-210 1 5421
Blower Adapter Plate – PF-399 1 5610
22
Swirl Plate – PF-210, Grey 1 54251
Swirl Plate – PF-399, Black 1 54252
23
Gas Valve – PF-210, includes item #22 1 54253
Gas Valve – PF-399, includes item #22 1 54254
Vent Termination Kits
–
3" Polypropylene Vent/Inlet Adapter (Innoflue ISAGL0303)
–
54632
–
4" Polypropylene Vent/Inlet Adapter (Innoflue ISAGL0404)
–
54633
–
3" Polypropylene Vent/Inlet Adapter (PolyPro 3PPS-AD)
–
54630
–
4" Polypropylene Vent/Inlet Adapter (PolyPro 4PPS-AD)
–
54631
–
3" Concentric Sidewall Termination Kit (PolyPro 3PPS-HK)
–
54498
–
4" Concentric Sidewall Termination Kit (PolyPro 4PPS-HK)
–
54499
–
3" Concentric Vertical Termination Kit (PolyPro 3PPS-VK)
–
54500
–
4" Concentric Vertical Termination Kit (PolyPro 4 PPS-VK)
–
54501
