PeerlessBoilers PF-50 - Page 55

53
REPAIR PARTS
Description
Quantity
Required
Stock Code
1 Panel, Jacket Front Door, with Ball Studs 1 54168
2 Lens for Jacket Front Door 1 54167
3 Display Module, Argus 852RC 1 54104
4 Gasket for Display Bracket 1 54153
5 Bracket for Display Module 1 PF2007
6 Hex Nut, #6-32 w/ Lockwasher 2 51553
7 Screw, #6-32 x 1/2 LG Phillips Head 2 5449
8 Gas Valve Line, Flexible 1 54129
9 Gasket for Gas Line 1 54142
10 Nipple, 1/2" NPT x Close 1 99211
11 Manual Shut-off Valve, 1/2" NPT 1 54130
12 Screw, #10x1/2" LG Hex Hd 2 99992
13 Coupling, 1"NPT SS 2 5424
14 Nipple, 1" NPT x 6" LG SS 2 5423
15
Jacket Side Panels - PF-50, PF-80 1 54173
Jacket Side Panels - PF-110, PF-140 1 54192
17 Bulk Head Fitting for Condensate Hose 1 54140
18 Gasket for Bulk Head Fitting 1 54134
19 Leg Leveler 4 5429
20 Hook Bolt 2 5451
21 Convenience Outlet 1 54136
22 Hex Nut, 8-32 with Lockwasher 4 51573
23
Control Module, 852MN - PF-50 1 54162
Control Module, 852MN - PF-80 1 54163
Control Module, 852MN - PF-110 1 54164
Control Module, 852MN - PF-140 1 54165
24 Switch, Round Toggle, 120 VAC 1 6049
25 Vent / Air Inlet Adapter 1 54135
26 Gasket, Vent Adapter 1 54133
27 Screw, #10 x 5/8"LG Phil Pan HD Type A Zinc 6 5507
-– Wiring Harness, Power (Right Terminal Block) 1 PF7002
-– Wiring Harness, Control (Left Terminal Block) 1 PF7003
-– Wiring Harness, Blower 1 PF7005
-– Wiring Harness, Ground Wire 1 PF7009
-– Push-on Terminal Block (Field Wiring) 2 5450
-– Ignition Cable 1 54115
-– Rocker Switch 1 6049
-– Relief Valve, 30 PSI 1 50664
-– Flue Sensor, 12K, TSD20B1 1 54111
-– Supply Sensor / Limit, 12K, TSDS955 1 54110
-– Return Sensor, 12K, TSD00BS 1 54109
-– Outdoor Sensor, 12K, TSA00B4 1 54112
-– DHW Sensor, 12K Optional 54157
-– System Sensor, 12K, TSA00BC Optional 54156
-– PVC Concentric Vent Terminal Optional 91403
-– Stainless Steel Vent Terminal Optional 54161
