13
6 Adjust the height of the supporting foot by
pressing the lever at the base of the foot until
it touches the vehicle floor (it is important that
the foot be resting firmly on the vehicle floor,
even if this means the base is raised slightly
above the vehicle seat).
If there is a storage compartment in the floor
of your vehicle in the area where the leg rests,
open the compartment lid and rest the leg on
the base of the compartment.
7 The base has a rotating attachment plate. To
place the plate in the desired position, press
the lever near the leg (1) and, at the same
time, rotate the plate until it clicks (2).
8 The indicators on the side of the lever are
green when the rotating plate is correctly
attached and positioned either forward-facing
or rear-facing. If they are red, the plate is
sideways or the attachment is not correct.
IMPORTANT: if the indicators are red, do
not use in a moving car.
Using with Primo Viaggio SLK
9 Hold the car seat from the handlebar and attach
it to the base by pressing down on the product
with both hands until it clicks into place.
IMPORTANT: the two indicators on the side
of the base will turn from red to green to
show that it has been connected correctly.
IMPORTANT: after completing the
operation, try moving the car seat to verify
it has been connected correctly.
10 The handlebar must be rotated all the way
forward, close to the back of the vehicle seat,
as shown in the figure. Press the two buttons
on the handlebar, rotate it and position it
towards the vehicle seat, as shown in the
figure, until it clicks.
11 To rotate the infant seat on the base (only for
sitting or removing the child from the seat),
press the lever near the leg (1) and, at the
same time, pull the car seat from one side so
that it rotates on the base plate (2).
IMPORTANT: if the indicators of the rotating
plate are red, do not use in a moving car.
12 To release the car seat from the base, put the
handlebar in the carry position and pull the
lever on the back while simultaneously lifting
the car seat.
Using with Primo Viaggio Lounge
13 Pull out the rebound bar from under the base
until fully extended, as shown in the picture.
14 Before attaching the car seat onto the base,
check that the backrest is in position 1 or 2,
acting on the handle on the top part of the
backrest.
IMPORTANT: do not attach Primo Viaggio
Lounge on the Base Twist with the backrest
in position 3.
15 Proceed with attaching the car seat onto the
Base Twist until it clicks into place. To rotate the
car seat on the base, proceed as in point 11.
16 The handlebar must be rotated all the way
forward, close to the back of the vehicle seat,
as shown in the figure. Press the two buttons
on the handlebar, rotate it and position it
towards the vehicle seat, as shown in the
figure, until it clicks.
17 To release the car seat from the base, put the
handlebar in the carry position and pull the
lever on the back while simultaneously lifting
the car seat.
Using with Viaggio Twist
in rear-facing position
18 Check the rebound bar is in the slot under
the base when using Viaggio Twist.
Attach Viaggio Twist by positioning it on the
Base Twist near the connectors (check the
base shape matches) and pushing downwards
until it clicks.
Make sure that the red/green indicators on
the side of the rotating plate are in the green
position.
IMPORTANT: the two indicators on the side
of the base will turn from red to green to
show that it has been connected correctly.
IMPORTANT: after completing the
operation, try moving the car seat to verify
that the Isofix fittings have been connected
correctly.
19 Rotate the infant seat to rear-facing position by
pressing the lever near the leg (1) and, at the
same time, pulling the car seat from one side
so that it rotates on the base plate (2).
20 When this step is complete, check that the
indicators on the side of the rotation lever
have turned green.
21 To sit and remove the child more easily, rotate
the car seat sideways, so it is facing the side
door of the vehicle. In this case, the indicators
on the side of the rotation lever are red.
IMPORTANT: if the indicators of the rotating
plate are red, do not use in a moving car.
22 To release Viaggio Twist from the Base Twist,
pull the lever at the front, under the seat, and
simultaneously lift the car seat.
Using with Viaggio Twist
in forward-facing position
23 Check the rebound bar is in the slot under
the base when using Viaggio Twist.
Attach Viaggio Twist by positioning it on the
Base Twist near the connectors (check the
base shape matches) and pushing downwards
until it clicks.
Make sure that the red/green indicators on
the side of the rotating plate are in the green
position.
- Repeat the steps of picture 21 to rotate the
seat while sitting or removing the child from
the car seat.
- To release the car seat from the base, repeat
the steps in picture 22.
IMPORTANT: do not use Viaggio Twist in
forward-facing position if the child is less
than 15 months old and, after that, only if
their height is above 76 cm.
IMPORTANT: if the indicators of the rotating
plate are red, do not use in a moving car.
Releasing the Base Twist
24 To remove the base from the vehicle seat,
press the safety tab 1 and the release button 2
on both side levers (a) and, at the same time,
pull the levers themselves, shifting the base
away from the seat. Push the connectors inside
the base (b), until they are all the way in (3).
25 Rotate the rebound bar (c) and the leg (d) and
fold them into their specific slots under the base.
Serial numbers
26 Inside the compartment of the Base Twist, you
can find information such as:
- product name, production date and serial
