Optional Accessories:
• Hand Controller
Controller Care
• Controller is not waterproof and it should be kept clean and dry. Moisture can damage electronics and connectors.
• Do not allow solvents or chemicals to come into contact with the device
• Store controller indoor in a dry room when not in use
• Do not touch the internal components as they may get hot when in use
Stepper Motor
FocusCube has an embedded high resolution geared stepper motor (Step Angle (Deg) 7.5 / 120 (Gearbox reduction rate =
0.06255 Deg per step). Its gearbox has low backlash and high torque suitable to focus in micron scale.
DO NOT TRY TO MOVE THE MOTOR MANUALLY WITHOUT POWER. MOTOR ACTS A BREAK AND TRYING TO ROTATE
SHAFT OF MOTOR MANUALLY MIGHT CAUSE DAMAGE TO THE METAL GEARS OF THE MOTOR. USE ONLY THE HAND
CONTROLLER.
Power Supply
Unit has been designed with reverse polarity protection. If you accidentally reverse the DC power source polarity the unit will cut
the power.
The controller is fitted with a standard 2.1mm center positive DC power connection which powers on the controller. It can accept
DC 11-15V. Please use a power supply that can provide DC 12V-13.8V / 1.5A (at least).
Insert the 2.1mm plug on the DC power cable. Controller will initialize (led will fast blink 4 times) and the green led with turn on
after 4 seconds.
