8. Connect the steam tube in the cylinder flange sleeve fixing it with the provided strap (fig. 13, 14
and 15).
Fig. 13 Fig. 14 Fig. 15
Use only PEGO HUMIDIFIERS steam tube or other tube with certification guaranteeing
use with high temperatures without internal vulcanisation processes and release of toxic
substances!
DO NOT MAKE THROTTLES, SIPHONS OR LENGTHS GREATER THAN
5 METRES!
To connect correctly the steam distribution line, carefully read chapter 8 STEAM
DISTRIBUTION.
