Pego ECP200 BASE 4A User Manual

E. BOARD ECP200 BASE 4/4A
Page 3
USE MANUAL
Rev. 02-18
TECHNICAL CHARACTERISTICS OF THE ELECTRONICS BOARD
Power supply of the electronics board
Voltage
230 V~  10% 50-60Hz
Max power (only electronics)
~ 7 VA
Rated current
(With all loads connected)
16A
Climatic conditions of the electronics board
Working temperature
-5 ÷ +50 °C
Storage temperature
-10 ÷ +70 °C
Relative ambient humidity
Lower than 90% Hr
General characteristics of the electronics board
Type of sensors that can be connected
NTC 10K 1%
Resolution
0,1 °C
Sensor read precision
± 0,5 °C
Read range
-45 ÷ +45 °C
Output characteristics of the electronics board (free voltage contact)
Description
Installed relay
Card output characteristics
BASE 4
BASE 4A
Compressor
(Relay 30A AC1)
10A 250V~ (AC3) (2HP)
(100000 cycles)
X
X
Elements
(Relay 30A AC1)
16A 250V~ (AC1)
X
X
Fans
(Relay 16A AC1)
2,7A 250V~ (AC3)
X
X
Room light
(Relay 16A AC1)
16A 250V~ (AC1)
X
X
Alarm / Aux (Optional)
(Relay 8A AC1)
8(3)A 250V~
X
CHAP. 1 - Technical characteristics
CHAPTER 1: TECHNICAL CHARACTERISTICS
1.1

Pego ECP200 BASE 4A Specifications

General

Brand	Pego
Model	ECP200 BASE 4A
Category	Control Unit
Language	English
