Pego ECP200 BASE 4A User Manual

E. BOARD ECP200 BASE 4/4A
Page 9
USE MANUAL
Rev. 02-18
Pc
Compressor protection contact status
0 = NO
1 = NC
0 = NO
doC
Compressor safety time for door
switch. When the door is opened the
evaporator fans shut down and the
compressor will continue working for time
doC, after which it will shut down.
0…5 min
0
tdo
Compressor restart time after door
opening. when the door is opened and
after tdo time, it’s setted back the normal
functioning giving door open alarm (Ed).
With tdo=0 the parameter is disabled.
0…240 min
0 = disabled
0
Fst
FAN shutdown TEMPERATURE
The fans will stop if the temperature value
read by the evaporator sensor is higher
than this value.
-45…+45°C
+45°C
Fd
Fst differential
0…+10°C
2°C
LSE
Minimum value attributable to setpoint.
-45... HSE °C
-45°C
HSE
Maximum value attributable to setpoint.
+45... LSE °C
+45°C
tA
NO – NC alarm relay switching
0 = activates when alarm is
on
1 = deactivates when alarm is
on
1
AU
Auxiliary/alarm relay control
0 = alarm relay
1 = manual auxiliary relay
controlled via AUX key
2 = automatic auxiliary relay
managed by StA temp.
setting with 2°C differential
3 = relay disabled / TeleNET
function
4 = pump down function
(see CHAP 5.15)
5 = free voltage contact for
condensing unit (AUX relay
and compressor relay in
parallel)
6 = contact for casing element
control (AUX relay closed
with compressor output
inactive).
7 = relay disabled / Modbus-
RTU function
0
StA
Temp. setting for aux. relay
-45…+45°C
0
In1
Man in cold room alarm
Select input INP1 on the board as
compressor protection alarm or as man in
cold room alarm (contact NC).
0 = compressor protection
1 = man in room alarm
0
