User’s manual
9
EN
SAFETY INSTRUCTIONS
Please read this operation instruction carefully
before use, and keep it for future reference.
Producer does not take responsibility for damages
caused by inappropriate handling and use of the
product.
1. Make sure to perform connections when the
vehicle engine is turned o.
2. Protect this device from water, humidity and
other liquids. Avoid using/storing it in extreme
temperatures. Do not expose this product to
direct sunlight, heat sources, or use near strong
magnetic elds. Do not handle this appliance
with wet hands.
3. It is suggested that all connections and mounting
should be carried out by qualied personnel.
4. Make sure all the connections are executed in a
proper manner. Reversed connection will cause
short circuit and damage.
5. Keep away from ammable materials!
6. Do not attempt to repair this appliance yourself.
In case of damage, contact authorized service
point for check-up/repair.
WIRING DIAGRAM
For proper installation of the system please refer to
below illustration.
1. Learning button
2. turn lights
3. window closer output (-)
4. trunk release (+/-)
5. siren (+)
6. Trunk release (+/-) (optional)
7. 3,5 s Pneumatic door lock / 0,5 s Electric door
lock
8. LED indicator
