6. INCIDENTS AND TROUBLESHOOTING
6.1. SUMMARY OF GAUGE DISPLAY AND BEEP MESSAGES
Normal messages
Use
fixed
Battery charge level (0 to 99)
with 1 beep per minute
Battery empty, recharge immediately
flashing with 1 beep every 10 seconds
Stop using, recharge immediately
Charging
flashing every 4 seconds
Battery charge level (0 to 99)
fixed
Charging complete
Storage
flashing
Standby mode after 4 days of non-use (17 to 99)
Indicator off Goes into storage after 7 days of non-use or voltage too
low
Degraded mode messages
Use
and alternately
Stop the tool; the battery temperature is too high
Long beep and 1 short beep Stop the tool: intensity is too high
Long beep and 4 short beeps Stop the tool; the tool temperature is too high
Charging
and alternately
Charge interrupted: Battery temperature too low
and alternately
Charge interrupted: Battery temperature too high
Fault messages
Using the tool
and beeps every 2 minutes for 24 hours
Voltage too low after 3 hours of non-use. Recharge battery im-
mediately
Charging
and alternating and continuous beep
Battery problem
and alternately
Charger problem
If your tool no longer works:
1. Set the switch (2) to the off position «0».
2. Check the battery is charged, as shown on the gauge.
3. Check the lead is connected and the cable thumb-wheel tightened.
4. Set the switch (2) to the on position «I». Press the trigger and the safety lock (depending on the tool).
5. If the tool does not work, return the complete equipment in its original packaging to a certified repair service.
Warning
Never attempt to open one or more elements of the "battery" or the charger unit (you risk
damaging them and most importantly, you void the warranty).
